Specifications
| Model | AB803 |
| Woofer Speaker Size | 8" |
|
Max Output Power |
450W |
| RMS Output Power | 150W |
| Built-in Amplifier Type | Class AB |
|
Frequency Response |
20Hz-150Hz |
|
Impedance |
2 Ω |
|
S/N Ratio |
91dB |
| Input Sensitivity(Distortion level 1%) |
RCA input 110mV, Speaker input 0.5V |
| Working Voltage | 14.4V(10-16V) |
| Phase Switch | 0°/180° |
| Auto Turn ON/OFF | High level input only |
| Fuse | 25A |
| Radiator Speaker Size | 192x60mm x2 |
| Woofer Cone Material | Aluminum |
| Woofer Magnet Material | Ferrite |
| Enclosure Material | Cast Aluminum Sealed Enclosure |
| Product Dimensions |
355x265x75mm |
| Net Weight |
5.6kg |
Packaging
